Issued June 2020
Operation
Copyright 2020, Heil Environmental
Printed in U.S.A.
66
OPERATION SPECIFICATIONS
Pump System
The pump will be on only when the in-cab red
SYSTEM POWER switch is activated, the pump
push button is ON (Green), the hopper side door is
closed and locked, and the filter is not in by-pass
mode.
The pump will be active when the above conditions
are met and the packer is activated.
The lift will function in neutral or in gear when foot
brake is applied and the RPM is below 900.
The lift will grab, lift, lower and release in 6-8
seconds at engine idle (700 RPM).
See Pump .
Packer
The packer will complete one cycle (extend and
retract) in 12-14 seconds at 1200 RPM.
The packer will slow during lift operation.
The packer will function at any RPM.
Triggered off the grabber release push-button, this
system initiates a pack cycle once the programmed
number of lift cycles have been completed. (Factory
pre-set is two (2) lift cycles). See Features and
Select-O-Pack Adjust Screen for more
information.
Auto-Lift
In Normal Coordinated Mode, the Grabber Close
function will initiate a Auto-Lift sequence. The
Operator's hand must remain grasped around the
Joystick during entire Auto-Lift sequence.
Cart will raise and retract automatically to the dump
position.
Operator manually replaces cart to desired position
on the ground.
Pressing the STOW POS button on the Supporting
Functions Push Button Controls will return lift
to stowed position.
See Features for more information.
154
64
103
72
64
