SENSORS
A.Hydraulic Oil Temperature Sensor
Hydraulic Oil Tank
B.Lift Position Sensors
Raise Sensor - Inside Cylinder, J1939
Extend Sensor - Inside Cylinder, J1939
Grabber Open/Close Sensor - Inside Cylinder, J1939
Head Rotate Sensor - Side of Hydraulic Actuator
Motor, Dual Channel Encoder, Field Replaceable
C.Packer/Ejector Position Sensor
Body - Street Side Corner of Front Head, Arc Sensor
D.Pressure Transducers (0-3600 PSI)
Body Pressure - Body Valve
Lift Pressure - Lift Valve
Grabber Pressure - Grabber Hydraulic Tubing
Dump Rotation Pressure - Dump Rotation Hydraulic
Tubing, weigh cans (<350 lbs) on-the-fly; can be
disabled
