CNG FUEL SYSTEM TROUBLESHOOTING (CONTINUED)
The following table lists possible problems, along with causes, corrections, and results.
CORRECTIVE/DIAGNOSTIC
ACTIONS
Heil Standard CNG and
Solenoid System
Options:
In-cab fuel gauge does not
indicate the fuel level
correctly.
The fuel module pressure
transducer, the fuel gauge
or the interconnecting
wiring may be defective.
Confirm that the 12-pin
electrical connector at the rear
of the fuel module is connected
and place the vehicle's ignition
switch in the "Run" position.
Use a voltmeter to read:
Voltage between connector
positions 2 (RED) and 3
(BLK). the voltage should be
12 vdc.
Voltage between connector
positions 3 (BLK) and 4
(WHT). the voltage should
be between 0.5 to 5.0 vdc.
*If the voltage across 2
and 3 is 0 or significantly
below battery voltage,
there is a problem with the
vehicle's wiring not
supplying power to the fuel
module's pressure
transducer.
*If the voltage across 3
and 4 is either 0 or 5.5
vdc, the fuel module's
pressure transducer is
most likely defective. Call
866-310-4345 for technical
assistance.
*If the voltage across 3
and 4 is between 0.5 to 5.0
vdc then the fuel module's
pressure transducer is
operating correctly. The
problem is likely in the
vehicle's wiring or the in-
cab fuel gauge.
*If the problem cannot be
resolved, call 866-310-
4345 for technical
assistance.
