PROPPING THE BODY OF A SERVICE HOIST
UNIT (CONTINUED)
Raising the Body (Continued)
7. NEVER open the override valve when the body is
elevated.
8. Perform the maintenance or service procedures.
Lowering the Body
1. PRESS the UP button until the body is not resting on
the body props.
2. RAISE the body props and store the handles.
3. Press and hold the DOWN button to lower the body.
4. Release the DOWN button when the body is
completely down and resting on the chassis.
5. OPEN the manual override valve – PUSH the knob
IN and turn it COUNTER-CLOCKWISE.
6. Make sure the manual override valve is open –
PUSH the service hoist UP button. The body will not
raise.
7. If any hose clamps were removed to create adequate
slack during body raise, then re-install those hose
clamps.
8. If equipped with quick disconnects, reattach the quick
disconnects.
9. Install the bolts and springs to the chassis mounting
brackets.
