Issued June 2020
Operation
Copyright 2020, Heil Environmental
Printed in U.S.A.
78
PROPPING THE BODY OF A SERVICE HOIST
UNIT (CONTINUED)
Factory Body Props
The factory-supplied body props are located on both sides
under the body and forward of the rear wheels. Carefully
follow the body propping procedures below.
Follow These Steps:
Raising the Body
1. Empty body of all refuse.
2. Make sure that body is on firm, level ground with the
Parking Brake engaged and holding and place
chocks on the wheels.
3. CLOSE the manual override valve on the power unit
– PUSH the knob IN and turn it CLOCKWISE.
4. Lock-Out/Tag-Out the unit.
5. Remove the bolts and springs from the chassis
mounting brackets. See the figure below.
Figure 44. Removing Bolts and Springs from
Chassis Mounting Brackets
Raising the Body (Continued)
1. If equipped with quick disconnects, uncouple prior to
raising the body.
2. Make sure there is adequate slack in hoses that do
not have disconnects. If there is not adequate slack
in hoses that do not have disconnects, remove those
hose clamps.
3. Observe and obey the DANGER labels for an
elevated chassis.
4. PRESS and HOLD the UP button to RAISE the body.
5. RELEASE the UP button when the body is at the
height you want.
6. Release the prop handles and LOWER the body
props, then PRESS the DOWN button to lower the
body onto the lugs. See the figure below.
Figure 45. Factory Body Props
To Next Page
