Issued June 2020
Operation
Copyright 2020, Heil Environmental
Printed in U.S.A.
68
OPERATION MODES
There are several Operation Modes available to Operators.
Some modes should only be used by Authorized Service
Personnel, such as Service and Calibration Modes.
WARNING
Moving equipment can be dangerous. Serious injury or
death may occur if a person is in the wrong area or is not
attentive to the operations. Clear the area of all
unnecessary people before you operate the controls.
A.Normal Mode
1. Description: Allows for normal operation for container
picks with the lift arm
2. Interlocks: All
3. How to Activate/Deactivate: Automatically activates/
reactivates with Key Switch
B.Weigh Mode
1. Description: Allows for normal operation for container
picks with the lift arm, weighing each can and saving
total route collection weight
2. Interlocks: All
3. How to Activate/Deactivate: Automatically activates/
reactivates with Key Switch
C.Coordinated/Manual Mode
1. Description: Switches between Joystick controls and
Manual Control Key Pad controls
2. Interlocks: All
3. How to Activate/Deactivate: Display (defaults to
Normal Mode with Key Switch)
D.Spear Mode
1. Description: Prepositions the lift arm and grabber for
quicker container picks.
2. Interlocks: All
3. How to Activate/Deactivate: Display (defaults to
Normal Mode with Key Switch)
E.Above/Below Grade Mode
WARNING
In Above/Below Grade Mode, there are NO interlocks to
prevent the lift arm from striking the body or ground.
Extreme caution must be used when operating the unit in
this mode. Due to reduced visibility of the lift arm by the
operator, street side controls do not allow ABOVE /
BELOW grade mode functionality.
1. Description: Allows for above or below grade
container picks.
2. Interlocks: None (Use CAUTION)
3. How to Activate/Deactivate: Display (defaults to
Normal Mode with Ignition Key Switch)
