mechanic. The next few pages cover basic functionality. For additional information, see Body Controller Software .
For the operator, it shows operation warnings and explains why the system may prevent a function so the operator can
correct and operate in a safe and productive manner.
For the service technician, it displays information regarding sensor failures, and with proper training, can be used to test
sensors and other inputs and output functions.
Circle Buttons 1-4 below the screen - correspond to menu items listed on the screen (directly above the buttons) and
vary from page to page
OK Button - selects items on the screen
UP Arrow - scrolls up while in menu screen
Right Arrow - momentarily toggles to display controls while camera view is active
Down Arrow - scrolls down while in menu screen
Left Arrow - acts as backspace while in password screen
Diagnostic Display Messages
When a fault occurs, the In-Cab Alarm will sound and a diagnostic message will be displayed with the status of respective
Input / Output in the Insight display unit.
See the Body Controller Software Section for for display screen shots of potential diagnostic messages, listed
disabled functions and instructions for fault reset.
