When installing a new pump, you MUST prime (fill) the
new pump with hydraulic fluid BEFORE operating,
otherwise damage WILL occur.
When replacing or re-installing the hydraulic pump after
repairs, the housing of the pump must be filled with
hydraulic fluid through the case drain port, either before or
after mounting the transmission.
1. Attach case drain hose between the pump
connection and the reservoir.
2. Connect the inlet hose to the rear of the pump and
reservoir. After filling reservoir, loosen top adapter
screws on the inlet and rotate hose adapter down,
cracking the top of the adapter away from the pump.
1. Open the tank shut-off valve to purge as much air as
possible out of the hose, filling the inlet hose with oil.
2. Tighten the inlet retainer screws, top off fluid level of
the reservoir if necessary.
