Screen Pages
Structure of the screen pages
1 Ventilation mode display field
2 Alarm message display field
3 Curves and measured values display field
4 Measured values display field
5 Information bar
Main page
Displays a pressure curve and displays three measured values.
To configure combination of measured values, see page 49.
or:
Displays a flow curve and displays three measured values.
To configure combination of measured values, see page 49.
