Dräger Savina

Configuration
51
Display in information bar:
Replace flow monitoring
or
Replace O
2 monitoring
or
Replace flow monitoring and O2 monitoring
Flow monitoring is automatically activated each time Savina is
switched on.
When flow monitoring is deactivated, Savina does not
determine the following measured values:
—MV
— MVspont
Even when O2 monitoring is deactivated, the devices requires
at least sensor 1 for accurate O2 control. Otherwise it delivers
inaccurate O2/air mixes.
O2 monitoring should only be deactivated when Savina is
supplied with air only.
O2 monitoring remains deactivated even when the device
is switched on again.
Display in alarm line:
!! O2 monitoring off
On acknowledging by pressing the »Alarm Reset« key,
display:
! O2 monitoring off
● Reactivate the monitor function after replacing the sensor.
Pmax ON/OFF
To use the pressure limit Pmax in the IPPV, IPPVAssist and
SIMV, SIMV/ASB ventilation modes.
The pressure limit value is set by means of the »Pinsp« key.
Savina limits the airway pressure to that set value.
● Press »Config. ∆∆« key repeatedly until
»Configuration 2/4« appears.
● Select »Pmax« line = turn rotary knob,
to release for setting = press rotary knob.
● To set »ON« = turn rotary knob,
confirm = press rotary knob.
The pressure limit »Pmax« is activated.
● To set »OFF« = turn rotary knob,
confirm = press rotary knob.
The pressure limit »Pmax« is deactivated.
079 37388
