Preparation
81
Fitting the flow sensor
1 Push the socket to the left as far as it will go.
2 Insert the flow sensor, with the probe facing towards the
ventilator, into the mounting and push it into the socket
as far as it will go.
Then:
3 Push flow sensor to the right as far as it will go into the
rubber lip of the expiration valve.
Fitting the bacterial filter
An inspiratory bacterial filter is necessary to protect the patient
from contamination from the ambient air drawn in.
● Push bacterial filter on to inspiration port.
029 37261
2
1
3
034 37261
