Dräger Savina

Care
68
Care
● Observe the hospital hygiene regulations.
● Clean and prepare the machine after each patient.
Recommendation:
● Change the hose system and expiration valve every week.
Keep the replacement systems ready.
Dismantling
Removing parts
● Switch off the ventilator and breathing gas humidifier,
and remove their power plugs.
1 Drain condensate from water traps and ventilation hoses.
Drain the water trap on the expiration valve.
2 Drain the water container of the humidifier.
Ventilation hoses
● Remove ventilation hoses from the device ports.
● Remove the water traps from the ventilation hoses.
Remove the water containers from the water traps and
the expiration valve.
● Prepare the ventilation hoses, water traps and associated
water jars, and the Y-piece for disinfection and cleaning
by autoclaving.
3 Remove the bacterial filter and treat it in accordance with
the accompanying instructions for use.
109 29 170
1
1
2
1
110 29 170
3
