Ducati MULTISTRADA V2 - Page 315

The 30 A fuse (11) and a spare fuse (12) are located on
the solenoid  Remove the fuse cap to reach it
(B).
To reach the 30 A main fuse (13), remove the cap (C)
 removing the  protective cover as
described in chapter “Charging the 
To reach ABS fuses (14) and (15), remove the
protective caps (D).
30
30
30
10
2
5
14
11
13
C
B
12
15
D
Fig 267
314
