Lower the lever (3) towards the rear side, until it is
fully home.
Close the handle (2) and turn the key anticlockwise to
lock the bag.
Remove the key.
Make sure the bag is fixed correctly by pulling the
bag gently to the side and also checking the
swinging movement.
Repeat the same operation for assembling the other
side bag.
Install both bags, check the swinging movement of
both, moving them to the right and on the rear
side of the bags.
If there are any problems with the movement,
contact a Ducati Dealer or Authorised Service
Centre.
Pay to the safe positioning of your
hands when checking the swinging movement.
Fig 27
Fig 28
48
