Installing the aluminium side panniers (if any)
To fit/remove the subframe kit for aluminium
side panniers and to set it to “floating” or “fixed”
mode, please contact your Ducati Dealer or
authorised service centre.
To carry out all opening / closing or
installation / removal operations on the panniers,
operate only the appropriate levers and never use
the key to transmit force.
Position the fixing hooks (1) at the of the
pannier frame as shown in the figure. the
pannier retaining clip (2) at the top of the pannier
frame (3) until you hear a “click”. Repeat the same
operations for the pannier on the side of the
motorcycle.
Fig 29
Fig 30
49
