Duplo DSC-10/20 User Manual

2-17
Chapter 2 Basic Operation
When using the block mode, load the paper as follows:
• Load interleaf 2 of the gure on the bottommost bin and interleaf 1 on the topmost bin of each
block.
A B
1
2
3
4
5
6
7
8
9
10
1
2
3
4
5
6
7
8
9
10
Block Mode 1/4
Block Mode 1/2
A B
1
2
3
4
5
6
7
8
9
10
1
2
3
4
5
6
7
8
9
10
No.1
No.2
No.1
Interleaf 1
Interleaf 1
Interleaf 1
Interleaf 1 Interleaf 1
Interleaf 2 Interleaf 2
Interleaf 2
Interleaf 2
Interleaf 2
P.3 P.3
P.3
P.3
P.1 P.1
P.1
P.1
No.2
No.3
No.4
P.8
P.1
Interleaf 1
Interleaf 2
P.8
P.1
2-6-6. Loading Procedure
Make sure not to insert your hands inside the paper feed bin while the suction belt or convey-
ance shaft is driving.
Otherwise you may get injured.
1
Load paper on paper feed bins.
Align the leading edge of the paper and load so that it presses against the shutter lightly.
Conrm that the paper does not contact the stack height sensor.
Do not load paper exceeding 35 mm/1.38 inches high.
(For North America)
(For North America,EU)
(For North America)
(For North America,EU)
