DURKOPP ADLER DAC BASIC - V 12-2010

© 2010 Dürkopp Adler AG
Loading and saving data
DAC basic/classic
44
11 Loading and saving data
L
C
P
Min
Max
Unit
Description
t
51
10
0
4
-
Loading parameters
0 =
Nothing;
1 =
Sewing data from DA dongle;
2 =
Sewing data from the back up area;
3 =
Seam runs from DA dongle;
4 =
Master Reset
t
51
11
0
3
-
Saving parameters
0 =
Nothing;
1 =
Sewing data on the DA dongle;
2 =
Sewing data in the back up area;
3 =
Seam runs on the DA dongle
When the dongle is being accessed parameter t 51 10/11 = 1 or 3 the red message LED flashes.
CAUTION
Only remove the dongle data memory from the port when the red LED has gone out.
Otherwise there is a risk of data loss and the control functions may no longer run
reliably.
11.1 Saving data on the dongle and back up/ mach ID
L
C
P
Min
Max
Unit
Description
t
51
11
0
3
-
Saving parameters
0 =
Nothing;
1 =
Sewing data on the DA dongle;
2 =
Sewing data on the back up area;
3 =
Sewing runs on the DA dongle
After selecting the saving medium with parameter t 51 11 and confirming by pressing button OK (19) , the seam
runs and the seam-specific parameters are saved on the this medium. If the medium is not available a message
will appear and no action will be triggered.
11.2 Importing data to the dongle and the back up/ mach ID
L
C
P
Min
Max
Unit
Description
t
51
10
0
3
-
Loading parameters
0 =
Nothing;
1 =
Sewing data from DA dongle;
2 =
Sewing data from the back up area;
3 =
Seam runs from DA dongle;
4 =
Master Reset
