User settings
DAC basic/classic
12
Examples for using the interlock segments
D = 2 -> Runs A and B are being machined
D = 3 -> Runs A, B and A are being machined
4.3 Setting the end interlock
The interlock signal is triggered by an adjustable number of stitches and the reverse trip is completed.
Button
Position
Setting
Settings
Display
3
Single interlock
Number
of interlock
stitches
The forward run is sewn with an adjustable number of stitches. Then the signal for the reverse feed lever is sent
and the reverse run is completed. The number of stitches can be set separately for both runs.
Button
Position
Setting
Settings
Display
3
Doppelriegel
Double interlock
Number
of interlock
stitches
4.4 Setting the multiple end interlock
Button
Position
Setting
Settings
Display
