DURKOPP ADLER DAC BASIC - V 12-2010 User Manual

Setting the basic functions
53
© 2010 Dürkopp Adler AG
12.9 Thread clamp and sewing foot pressure reduction
L
C
P
Min
Max
Unit
Description
t
01
00
0
4
-
Thread clamp mode
0 =
on switching angle FK = t0101,
out switching angle
FK = t0102,
Without FL;
1 =
on switching angle FK = 108°,
out switching angle FK = 268°,
Without FL;
2 =
on switching angle FK = 49°,
out switching angle FK = 110°,
Without FL;
3 =
on switching angle FK = 49°,
out switching angle FK = 190°,
Without FL;
4 =
on switching angle FK = 108°,
out switching angle FK 268°,
on switching angle FL = 108°,
out switching angle FL = 154°;
5 =
on switching angle FK = 108°,
out switching angle FK = 268°,
on switching angle FL = 44°,
out switching angle FL = 154°;
6 =
on switching angle FK = 30°,
out switching angle FK = 200°,
on switching angle FL = 50°,
out switching angle FL = 100°;
7 =
Without FK,
on switching angle FL = t0111,
out switching angle FL = t0112;
8 =
on switching angle FK = t0101,
out switching angle FK = t0102,
on switching angle FL = t0111,
out switching angle FL = t0112
t
01
01
0
359
°
Thread clamp power on angle
t
01
02
0
359
°
Thread clamp power off angle
t
01
11
0
359
°
Sewing foot elevation power on angle
t
01
12
0
time lag
°
Sewing foot elevation power off angle
t
01
13
0,0
10,0
%
Duty cycle of sewing foot lifting at mode 4-8
t
01
20
0
3
-
Thread clamp options
0 =
Thread clamp only at start of seam:
1 =
Thread clamp at start of seam and at turn back position;
2 =
FK at start of seam and with sewing foot elevation;
3 =
FK at start of seam, return position and with sewing foot
elevation;
Thread clamp function ON: Press
button. LED on
The thread clamp mode can be selected with parameter t 01 00.
