By selecting parameter t 51 12 anc confirming by pressing OK, the following tests can be selected with buttons
A+ and A-. Confirm test selection with OK.
1. Analog Display of various analog inputs, select with buttons A+ and A-
Interim circuit voltage Um : 230,0 [V]
Control voltage U24 : 24,0 [V]
Output current total of I/O's Imo : 3,0 [A]
Analog pedal Pan : 1024 <=> 3,3V
Reduced speed(X1.4) Nre : 1024 <=> 3,3V
Analog input(X1.1 Only DAC
classic
) Ian : 1024 <=> 3,3V
2. Inputs Inputs' test (sensors)
The function of all input components are checked automatically with this test. If the status of an input is changed,
this input and the status are automatically displayed on the screen.
Caution, danger of injury!
Only carry out an input test when the machine is running with the greatest care.
3. Output Outputs' test (actuators)
The available outputs are selected with buttons A+ and A-. The output can be set with button D+ and reset with
button D-.
Caution! Risk of breaking!
Switching output components may lead to collisions with other machine components and
damage to the sewing machine.
Before switching on each output component ensure that it cannot collide with other
components.
