Assembly instructions
DAC basic/classic
26
7 Assembly instructions
Before starting assembly, it is advisable to remove all parts from the packaging. The box contains the motor, the
control unit, the accessories and the operating instructions. Check the contents of the pack to ensure that
everything is there. If you have any questions about assembly that the operating instructions do not answer,
please contact us or one of our customer service workshops. Assemble the motor in accordance with the
individual instructions and illustrations.
7.1 Fitting the reference value transmitter
•
The reference value transmitter is fastened under the machine table with an assembly bracket.
•
The reference value transmitter's pull and push rod are connected to the machine pedal by a connecting rod.
•
Screw the assembly bracket for the reference value transmitter under the machine table so that the SWG push
and pull rod and the pedal connecting rod form as straight a line as possible in order to ensure the best transfer
of power between the SWG and the pedal.
•
The connecting rod and the pedal should form an angle as close to 90° as possible.
•
You must ensure that the pedal moves freely.
