DURKOPP ADLER DAC BASIC - V 12-2010

Setting the basic functions
47
© 2010 Dürkopp Adler AG
12.3 Maximum speed
L
C
P
Min
Max
Unit
Description
t
08
00
1
9999
rpm
Maximum speed
Important
You will find the sewing machine's maximum speed in the operating documentation for the corresponding machine
class.
12.4 Soft start
L
C
P
Min
Max
Unit
Description
t
05
00
120
1000
rpm
Soft start speed
t
05
01
1
99
Stitches
Number of soft start stitches
Soft start ON: Press the
button. LED on
Soft start OFF: Press the
button. LED off
Functions:
•
after the electricity has been switched on
•
when beginning a new seam
•
Speed is determined by the pedal and limited to the soft start speed.
•
the lower speed of a function running at the same time has priority (e.g. initial interlock, stitch counting)
•
Stop with pedal at position 0
12.5 Sewing foot lifting
Sewing foot lifting in the seam automatically ON: Press
button. LED on
Sewing foot lifting ON automatically after thread cut: press
button. LED on
