Setting the basic functions
51
© 2010 Dürkopp Adler AG
13 =
Needle cooling
12.7.2
Assigning the keypad
The keys are called smart keys which means that the different functionalities can be applied directly to these
keys.
These are programmed using the P key followed by pressing the corresponding key for about 2 seconds. Confirm
the selection by pressing OK.
L
C
P
Min
Max
Unit
Description
t
52
20 -
25
0
13
-
Setting the input function for the OP1000 "F" key
0 =
no function;
1 =
on threading help;
2 =
Bartack suppression/recall;
3 =
Manual bartack;
4 =
Half stitch;
5 =
Full stitch;
6 =
Direction finder position;
7 =
Turning back
8 =
Input function module 1;
9 =
Input function module 2;
10 =
Input function module 3;
11 =
Switch high lift for walking foot;
12 =
Ornamental Backtack;
13 =
Needle cooling
12.8 Thread cutting procedure
Thread cutter ON: Press
. LED on
L
C
P
Min
Max
Unit
Description
1
02
01
0
1
-
Pedal setting to start the cutting process.
0 =
Position -2;
1 =
Position -1
t
02
10
0
359
°
Power on angle t 08 12 <= t 02 10 < t 02 11
t
02
11
0
359
°
Power off angle t 02 10 <= t 02 11 < t 08 13
t
02
20
0
255
ms
Time lag for repeated switching on of the thread cutting magnets.
t
02
21
0
255
ms
Time lag for switching off the thread cutter magnets
