Error-, warning- and info-messages
DAC basic/classic
62
14 Error-, warning- and info-messages
The control DAC
basic
or DAC
classic
has got three groups of messages. In the following table this three groups are
described.
Grad
Kürzel
Beschreibung
Error
Err
Error
Switch off the control and eliminate the problem .
Warning
Wrn
Eliminate the state that caused to the warning. The control will normally worked.
Information
Inf
Information push the OK-button
Further working should be possible. It could be that only only emergency run features are
possible.
Grad
Code
Fehler- bzw. Info- Beschreibung
Abhilfe
Error
1000
Sewing motor encoder plug (Sub-D,
9 pin) not connected.
- Insert the encoder lead into the control unit. Use the
right interface.
Error
1001
Sewing motor error
Sewing motor plug (AMP) is not
connected.
- Check the connection and if necessary plug in.
- Test sewing motor phases (R= 2.8 Ohm, high
resistance compared with PE)
- Replace sewing motor
- Replace control unit
Error
1002
Sewing motor insulation error
- Check motor phase and PE for low-resistance
connection
- Replace sewing motor
Error
1004
Sewing motor turning in the wrong
direction
- Replace encoder
- Check that the motor plug is in the right place and
change if necessary
- Check wiring in the machine distributor and change if
necessary
- Test motor phases and check for value
Error
1005
sewing motor blocked
-Eliminate sluggish movement in the sewing machine
Error
1006
maximum speed exceeded
- Change the Encoder
- Reset the control unit
- Check the machine sub class ( t 51 04)
Error
1007
Errors in the reference movement
- Change the encoder
- Eliminate sluggish movement in the sewing machine
Error
1052
Excess sewing motor current,
internal current increase >25A
- Replace control unit
Error
1055
Sewing motor overload
- Eliminate sluggish movement in the sewing machine
Information
1203
Position not reached (for thread
cutting, turning round etc. )
- Check controller settings and if necessary change,
mechanical changes to the machines, e.g. thread
cutter setting, belt tension etc.)
- Check the thread lever up position (Position 2)
Error
3100
AC RDY timeout , intermediate
circuit voltage has not reached the
defined threshold in the given time.
- Check mains voltage
- If mains voltage OK, replace control unit
Error
3101
High voltage error, mains voltage
>290V for some time
- Check mains voltage, if rated voltage exceeded
permanently - stabilise or use generator
Error
3102
Low voltage failure (2nd threshold)
(mains voltage < 150V AC)
- Check mains voltage
- Stabilise mains voltage
- Use generator
