Error-, warning- and info-messages
63
© 2010 Dürkopp Adler AG
Grad
Code
Fehler- bzw. Info- Beschreibung
Abhilfe
Information
3103
Low voltage warning (1st threshold)
(mains voltage < 180V AC)
- Check mains voltage
- Stabilise mains voltage
- Use generator
Warning
3104
Pedal position is not at position 0
When switching on the control unit, take foot off pedal
Error
3105
Short circuit U24V
- 37 pin Take plug out, if error 3105 continues, replace
control unit
- Test inputs/ outputs for 24V short circuit
Error
3106
Overload U24V (I²T)
- one or more of the magnets faulty
Error
3107
Pedal not connected
- connect analogue pedal
Warning
3109
Maintaining safety
- Check the tipping sensor on the machine
Information
3150
Maintenance required (info)
- For information on lubricating the machine see the
machine's service instructions
Warning
3151
Maintenance required (continue only
when parameters reset
t 51 14, see machine's operating
instructions)
- carry out service urgently, see machine's service
instructions
Information
3215
Bobbin thread ounter (info value 0
reached)
- Change reel, set counter value - press counter reset
button
Information
3216
Bobbin thread monitor left
- Change left bobbin
Information
3217
Bobbin thread monitor right
- Change right bobbin
Information
3218
Bobbin thread monitor left and right
- Change left and right bobbin
Error
6353
Internal EEprom communication
error
- Switch off control unit, wait until the LEDs go out and
turn on again.
Error
6351
External EEprom communication
error
- Switch off control unit, wait until the LEDs go out and
check the connection of the mach-ID. Turn the control
on.
Information
6360
No valid data on external EEprom
- Update software. The internal data structures are not
compatible with the external data memory
Information
6361
No external Eeprom connected
- Plug in mach ID
Information
6362
No valid data on internal EEprom
- Check connection mach-ID
- Switch off control unit, wait until the LEDs go out and
turn on again.
- Update software. The internal data structures are not
compatible with the external data memory
Information
6363
No valid data on internal or external
EEprom
(only emergency run features)
- Check connection mach-ID
- Switch off control unit, wait until the LEDs go out and
turn on again.
- Update software. The software version is not
compatible with the internal data memory
Information
6364
No valid data on internal EEprom
and external EEprom not connected
(only emergency run features)
- Check connection mach-ID
- Switch off control unit, wait until the LEDs go out and
turn on again.
- Update software. The internal data structures are not
compatible with the external data memory
Information
6365
Internal EEprom faulty
- Replace control unit
Information
6366
Internal EEprom faulty and external
data invalid
(only emergency run features)
- Replace control unit
Information
6367
Internal EEprom faulty and external
not connected
- Replace control unit
