E15h SPRAYER- Console Overview
1.0 MENU OVERVIEW
1.1 TO MOVE THE FOCUS AROUND THE SCREEN
• The buttons along the left hand side (LINE 1, LINE 2, LINE 3 AND LINE 4) of the
screen are aligned with a row on the screen.
• Pressing a left hand button will hightlight the first focus square on that row
• If there is no text on a row, you will not be able to set the focus to that row
• If a value is uneditable (ie a title or display value) you may not be able to set the
focus to that state.
• To move between windows on a single row, press the corresponding (LINE 1,
LINE 2,LINE 3 or LINE 4) button repeatedly. The focus will switch between available
fields on the row.
1.2 TO ENTER THE MENU FROM THE WORKING SCREEN
• Ensure the Master Switch is in the OFF (hold) position
• Press the MENU button
• You will be taken to the MAIN MENU screen
1.3 TO RETURN TO THE WORKING SCREEN
• Ensure that you are not editing a value (if you are editing a value an asterisk (*)
will be shown in the box the focus is set to)
• Press the MENU key
• You will be returned to the previous menu screen
1.4 TO ENTER A MENU SCREEN
• Highlight the field displaying the menu you wish to enter
• Press the ENTER key
• You will be taken to the corresponding menu
1.5 TO EDIT A VALUE
• Highlight the field displaying the value you wish to edit
• Press the ENTER button. An asterisk (*) will appear in the field you are editing
• Use the INC/DEC buttons to adjust the value
• Press the ENTER button to accept the changed value. The asterisk (*) will
disappear.
11
V 1.0 11/05
