Eagle KEE E15 - Enable Pressure1 Sensor; Setting the Pressure Gain; Setting the Type of Pressure Sensor

E15h SPRAYER- Sprayer Setup Operation
3.29 ENABLE PRESSURE1 SENSOR
Note: Select ON if a pressure transducer is fitted to the plug marked “PRESSURE
SENSOR” on the Sprayer Loom.
• Press MENU
• Press ENTER to select SETUP
• Press ENTER to select SPRAYER SETUP
• Press the DEC button to advance to the SPRAYER SETUP 2 screen
• Press the DEC button to advance to the SPRAYER SETUP 3 screen
• Press the DEC button to advance to the SPRAYER SETUP 4 screen
• Press LINE 1, to highlight PRESSURE1 SENSOR
• Press ENTER to edit the PRESSURE1 SENSOR.
• Press INC/DEC buttons, to enable the PRESSURE1 SENSOR ON or OFF
• Press ENTER to accept changes
3.30
SETTING THE PRESSURE GAIN
Note: PRESSURE GAIN is setting the gain for the pressure sensor connected to the
plug marked “PRESSURE SENSOR” on the “Sprayer Loom”. The default is “x2”
Only use “x1” if the Eagle E15h console was purchased before June 2005.
• Press MENU
• Press ENTER to select SETUP
• Press ENTER to select SPRAYER SETUP
• Press the DEC button to advance to the SPRAYER SETUP 2 screen
• Press the DEC button to advance to the SPRAYER SETUP 3 screen
• Press the DEC button to advance to the SPRAYER SETUP 4 screen
• Press LINE 3, to highlight PRESSURE GAIN (1)
• Press ENTER to edit the PRESSURE GAIN (1)
• Press INC/DEC buttons, select between 1x or 2x
• Press ENTER to accept changes
3.31
SETTING THE TYPE OF PRESSURE SENSOR
Note: PRESSURE SENSOR is sets the type of pressure sensor connected to the plug
marked “PRESSURE SENSOR” on the “Sprayer Loom”
The default is 5 BAR. Most sprayers will use this setting.
10 BAR Pressure Sensors is only used for special purposes like “Air Blast” sprayers
• Press MENU
• Press ENTER to select SETUP
• Press ENTER to select SPRAYER SETUP
• Press the DEC button to advance to the SPRAYER SETUP 2 screen
• Press the DEC button to advance to the SPRAYER SETUP 3 screen
• Press the DEC button to advance to the SPRAYER SETUP 4 screen
• Press LINE 4, to highlight PRESSURE SENSOR
• Press ENTER to edit the PRESSURE SENSOR
• Press INC/DEC buttons, select between 5BAR or 10BAR
• Press ENTER to accept changes
V 1.0 11/05
37
