E15h SPRAYER- Sprayer Setup Operation
Note: If no fans are to be monitored then set FAN MONITOR to OFF and set
FANS ENABLED to ‘0’
When FAN MONITOR is selected to OFF, then there is
no
FAN MONITOR ECU
fitted to the E15 h console. When FAN MONITOR is selected to ON, then there is
a FAN MONITOR ECU connected to the E15h console
If a ‘Fully Featured Horticultural Loom’ is fitted to the sprayer then up to 2 fan
imputs can be monitored, without the need to install a FAN MONITOR ECU. In
this case select FAN MONITOR to OFF and select either 1 or 2 from FANS
ENABLED.
If the Economy Horticultural Loom is fitted OR more than 2 fans need to be
monitored then a Fan Monitor ECU needs to be installed. In this case select FAN
MONITOR to ON and then select the number of fans to be monitored from FANS
ENABLED.
The Fan Monitor ECU can monitor up to 12 fans.
3.26 ENABLE FAN MONITORING
• Press MENU
• Press ENTER to select SETUP
• Press ENTER to select SPRAYER SETUP
• Press the DEC button to advance to the SPRAYER SETUP 2 screen
• Press the DEC button to advance to the SPRAYER SETUP 3 screen
• Press LINE 4, to highlight FAN MONITOR
• Press ENTER to edit the FAN MONITOR.
• Press INC/DEC buttons, to select either ON (if a FAN MONITOR ECU is
connected) OR OFF ( if
no
FAN MONITOR ECU is connected).
• Press ENTER to accept changes.
3.27
SET NUMBER OF FANS
• Press MENU
• Press ENTER to select SETUP
• Press ENTER to select SPRAYER SETUP
• Press the DEC button to advance to the SPRAYER SETUP 2 screen
• Press the DEC button to advance to the SPRAYER SETUP 3 screen
• Press LINE 4, to highlight FANS ENABLED
• Press ENTER to edit the FANS ENABLED.
• Press INC/DEC buttons, to set the number of fans to be monitored.
Note: If FAN MONITOR was selected to OFF, then only ‘0’ (monitoring no fans),
‘1’ (monitoring 1 fan) OR ‘2’ (monitoring 2 fans) can be selected.
If FAN MONITOR was selected to ON, then select between ‘2’, ‘4’, ‘6’, ‘8’, ‘10’, or
‘12’ fans to monitor.
• Press ENTER to accept changes.
V 1.0 11/05
35
