E15h SPRAYER- Operations: Sprayer
7.1 OPERATION OF THE SPRAYER
7.1.1.DISPLAY THE VOLUME REMAINING IN THE TANK
• VOLUME LEFT by default is displayed, on ‘Line 3’ on the left hand side of the
Working Screen. If it isn’t displayed then:
• Press the ‘Line 3’ button, then before the focus disappears, (after 5 seconds)
• Press the AUX button, (repeatedly if necessary) until VOLUME LEFT is displayed.
7.1.2
DISPLAY THE VOLUME USED
• VOLUME USED by default is displayed, on LINE 4 on the left hand side of the
Working Screen. If it isn’t displayed then:
• Press the ‘Line 4’ button, then before the focus disappears, (after 5 seconds)
• Press the AUX button, (repeatedly if necessary) until VOLUME USED is displayed.
7.1.3
FILL THE TANK
• Press and hold LINE 3 (button aligned next to VOLUME LEFT) button for 5 seconds
The volume of the tank will return to the tank volume, set in section 3.6.
7.1.4 FILL THE TANK TO A SET VOLUME
• Press LINE 3, the focus will be on VOLUME LEFT
• Press ENTER, to edit the volume.
An asterisk (*) will appear next to VOLUME
• Press INC/DEC buttons, to adjust the volume (in 50 Litre increments),to the required
volume
• Press ENTER, to accept changes.
7.1.5
TO DISPLAY SUB AREA, TOTAL AREA AND SUB AREA NUMBER
• Press LINE 2 SUB AREA will be highlighted
• Press AUX button once, SUB AREA NUMBER will be displayed
• Press AUX button once, TOTAL AREA, will be displayed
• Press AUX button once, SUB AREA, will be displayed again.
NOTE: The focus will stay on LINE 2 for about 5 seconds; and will stay there for 5
seconds each time the AUX button is pressed, while the focus is on LINE 2 on the SUB
AREA window, the AUX button may be used to switch between the three windows. .
What ever was displayed last will stay on the LINE 2 of the SUB AREA window.
7.1.6 SWITCH A SECTION ON
• Adjust the switch for the required section(s) to the ON, position.
By default down is ON.
• If the MASTER switch is OFF, the indicator LED for the section will flash
• If the MASTER switch is ON the indicator LED will be illuminated.
67
V 1.0 11/05
