Eagle KEE E15 - Set the Gain Setting; Set the Pwm Setting; Set the Flowmeter Sensitivity

E15h SPRAYER- Controller Setup
5.4 SET THE GAIN SETTING
• Press MENU
• Press ENTER to select SETUP
• Press LINE 3, the focus is on CONTROLLER SETUP
• Press ENTER to CONTROLLER SETUP
• Press LINE 3, the focus is on GAIN SETTING
• Press ENTER to edit GAIN SETTING.
An asterisk (*) will appear.
• Press INC/DEC buttons to set the value. Depending on the type of regulator
valve selected in Section 5.1, will determine what range of values (mS/%) are
available, there are four values to select from.
• Press ENTER to accept the changes
5.5
SET THE PWM SETTING
• Press MENU
• Press ENTER to select SETUP
• Press LINE 3, the focus is on CONTROLLER SETUP
• Press ENTER to CONTROLLER SETUP
• Press LINE 3, the focus is on PWM SETTING
• Press ENTER to edit PWM SETTING.
An asterisk (*) will appear.
• Press INC/DEC buttons to set the value. Depending on the type of regulator
valve selected in Section 5.1, will determine what range of values (%) are
available, there are four values to select from.
• Press ENTER to accept the changes
5.6
SET THE FLOWMETER SENSITIVITY
Note: DeFault is STANDARD
• Press MENU
• Press ENTER to select SETUP
• Press LINE 3, the focus is on CONTROLLER SETUP
• Press ENTER to CONTROLLER SETUP
• Press LINE 3, until the focus is on FLOWMETER SENSITIVITY
• Press ENTER to edit FLOWMETER SENSITIVITY.
An asterisk (*) will appear.
• Press INC/DEC buttons, to select between STD and LOW
• Press ENTER to accept the changes
58
V 1.0 11/05
