E15h SPRAYER- Controller Setup
5.1 SET CONTROL MODE
Note: This setting is selecting the type of regulator valve connected to the plug
marked ‘REG VALVE 1” on the “Sprayer Loom”. When the type of regulator valve
is selected, the defaults are automatically set for: “MAX ON TIME”, “MIN ON
TIME”, “GAIN SETTING” and “PWM SETTING”. There should be no need to alter
these defaults settings unless instructed by a KEE Service Person. If the regulator
valve being used is not listed then select “STANDARD”.
Standard Types: Arag Type, KEE Type, Hardi type Regulator Valves
Raven: Raven Fast Regulator Valves
Micro-Track: Micro-Track Regulator Valves
Dickey-John: Dickey John Regulator Valves
• Press MENU
• Press ENTER to select SETUP
• Press LINE 3, the focus is on CONTROLLER SETUP
• Press ENTER to CONTROLLER SETUP
• Press ENTER to edit CONTROL MODE. An asterisk (*) will appear.
• Press INC/DEC buttons to select between: STANDARD, RAVEN, DICKEY-J
(Dickey-John) and M-TRACK (Mirco-Track)
• Press ENTER to accept the changes
5.2
SET THE MAX ON TIME
• Press MENU
• Press ENTER to select SETUP
• Press LINE 3, the focus is on CONTROLLER SETUP
• Press ENTER to CONTROLLER SETUP
• Press LINE 2, the focus is on MAX ON TIME
• Press ENTER to edit MAX ON TIME
An asterisk (*) will appear.
• Press INC/DEC buttons to set the value. Depending on the type of regulator
valve selected in Section 5.1, will determine what range of values (mS) are
available, there are four values to select from.
• Press ENTER to accept the changes
5.3
SET THE MIN ON TIME
• Press MENU
• Press ENTER to select SETUP
• Press LINE 3, the focus is on CONTROLLER SETUP
• Press ENTER to CONTROLLER SETUP
• Press LINE 2, till the focus is on MIN ON TIME)
• Press ENTER to edit MIN ON TIME.
An asterisk (*) will appear.
• Press INC/DEC buttons to set the value. Depending on the type of regulator
valve selected in Section 5.1, will determine what range of values (mS) are
available, there are four values to select from.
• Press ENTER to accept the changes
