Eagle KEE E15 - Select Speed Source; Automatic Wheel Calibration; Manual Entry of Wheel Factor

E15h SPRAYER- Sprayer Setup Operation
3.8.1 SELECT SPEED SOURCE
• Press Line 4 to highlight SPEED SOURCE
• Press ENTER.
An asterisk (*) will appear.
• Use INC/DEC buttons to select STANDARD or RADAR.
• Press ENTER to accept changes.
3.8.2
AUTOMATIC WHEEL CALIBRATION
• Select Line 1 to highlight PULSES.
• Press ENTER to begin wheel factor calibration
• Drive forward a measured distance, say 100m.
The PULSES count will
accumulate as you travel forwards. The DISTANCE value and ESTIMATED value
will accumulate in metres as you travel forwards. These values will accumulate
reflecting the current WHEEL FACTOR value; if the value is close then then the
ESTIMATED and DISTANCE value will also be close to the actual distance
travelled.
The DISTANCE value is the value to be edited and the ESTIMATED value is
a display value only.
• Once the known distance is reached, press ENTER. Focus will
automatically jump to
DISTANCE line of the screen
• Use Inc/Dec buttons to change the DISTANCE value to reflect the actual
distance travelled
• Press ENTER to accept the value. The
Wheel factor will be automatically
calculated and displayed, on the SPEED CAL line.
3.8.3 MANUAL ENTRY OFF WHEEL FACTOR
• Press LINE 3 until the focus is on SPEED CAL
• Press ENTER to edit the value. An asterisk (*) will appear next to SPEED.
• Use INC/DEC buttons to change the wheel factor.
Wheel factor
changes in 1cm increments, when STANDARD is selected. The Increment
changes are a lot smaller when RADAR is selected.
• Press ENTER to accept the value
• Press MENU to go back to previous Sprayer Setup Screen
25
V 1.0 11/05
