E15h SPRAYER- Sprayer Setup Operation
3.23 SELECT DUMP MODE
Note: If connecting a DUMP VALVE to the ‘37 Pin’ plug marked DUMP on the
sprayer loom, then select STANDARD. STANDARD is the default. Normally
STANDARD is selected when using a ‘Fully Featured Horticultural Loom’.
If connecting the DUMP valve to the ‘24 Pin’ plug marked ‘SECT. 6’ on the
‘Economy Sprayer’ or using the ‘Horticultural Adaptor’ loom, then select ‘SECT 6’.
• Press MENU
• Press ENTER to select SETUP
• Press ENTER to select SPRAYER SETUP
• Press the DEC button to advance to the SPRAYER SETUP 2 screen
• Press the DEC button to advance to the SPRAYER SETUP 3 screen
• Press LINE 1, to highlight DUMP MODE
• Press ENTER to edit the DUMP MODE.
• Press INC/DEC buttons, to select the DUMP MODE as STANDARD OR SECT. 6.
• Press ENTER to accept changes
3.24
SET THE VALVE TYPE
*Note: If connecting the sprayer loom to ‘2 Wire Valves’ via an ARAG interface
then select SOLENOID as the VALVE TYPE.
Only select ‘2 Wire Valves’ as the VALVE TYPE when the sprayer loom connects
directly to the ‘2 Wire Valves’.
• Press MENU
• Press ENTER to select SETUP
• Press ENTER to select SPRAYER SETUP
• Press the DEC button to advance to the SPRAYER SETUP 2 screen
• Press the DEC button to advance to the SPRAYER SETUP 3 screen
• Press LINE 3, to highlight VALVE TYPE
• Press ENTER to edit VALVE TYPE.
An asterisk (*) will appear.
• Press INC/DEC buttons, to select between SOLENOID, 2-WIRE*
or 3-WIRE.
• Press ENTER to accept the changes
3.25
SET THE CONSOLE UNITS
Note: Default is METRIC.
• Press MENU
• Press ENTER to select SETUP
• Press ENTER to select SPRAYER SETUP
• Press the DEC button to advance to the SPRAYER SETUP 2 screen
• Press the DEC button to advance to the SPRAYER SETUP 3 screen
• Press LINE 3, to highlight CONSOLE UNITS
• Press ENTER to edit CONSOLE UNITS.
An asterisk (*) will appear.
• Press INC/DEC buttons, to select between: METRIC, IMP’L(IMPERIAL),
U.S.(U.S. IMPERIAL), CAN. IMP(CANADIAN IMPERIAL),
or CAN.MET(CANADIAN METRIC)
• Press ENTER to accept the changes
