Eagle KEE E15 - Set the Low Speed Shutoff; Set the Tank Volume; Application Mode

E15h SPRAYER- Sprayer Setup Operation
3.5 SET THE LOW SPEED SHUTOFF
Note: This sets the LOW SPEED SHUTOFF value, so when the boomspray slows
down below this value , the boom spray will turn all sections OFF, and the
sections will stay on HOLD, the regulator valve will hold the same position when
the ‘Low Speed Shutoff’ came into affect; till the boomspray increases speed
above the LOW SPEED SHUTOFF value.
• Press MENU
• Press ENTER to select SETUP
• Press ENTER to select SPRAYER SETUP
• Press LINE 2 button until the focus is on LOW SPEED SHUTOFF
• Press ENTER.
An asterisk (*) will appear after SPEED
• Use the INC/DEC buttons to change the LOW SPEED SHUTOFF value
• Press ENTER to accept the changes
3.6
SET THE TANK VOLUME
Note: This sets the size of the boomspray tank.
• Press MENU
• Press ENTER to select SETUP
• Press ENTER to select SPRAYER SETUP
• Press LINE 3 so the focus is on TANK VOLUME (1)
• Press ENTER.
An asterisk (*) will appear after TANK
• Use the INC/DEC buttons to change the tank volume.
Volume
changes in 50 litres increments.
• Press ENTER to accept the changes
3.7
APPL’N MODE (Application Mode)
Note: This sets the way application rate is displayed on the ‘Working Screen, the
Rate can be displayed as volume/area OR volume/distance; eg.‘L/Ha’ or ‘L/100m.
• Press MENU
• Press ENTER to select SETUP
• Press ENTER to select SPRAYER SETUP
• Press LINE 3 until the focus is on APPL’N MODE
• Press ENTER.
An asterisk (*) will appear after APPL’N.
• Use the INC/DEC buttons to select either ‘L/Ha’ or ‘L/100m’
• Press ENTER
to accept the changes.
23
V 1.0 11/05
