E15h SPRAYER- Sprayer Setup Operation
• With the focus on TOTAL WIDTH. Press the INC or DEC buttons, to select the
Preset Width to change, (1,2,3 or 4). The current TOTAL WIDTH and ROW
WIDTH will be displayed for that number.
• Press the LINE 3 button, the focus will be on the first Section to be set.
• Press ENTER to edit the section width.
An asterisk (*) will appear.
• Use the INC/DEC buttons to change the section width.
As the section is changed
the TOTAL WIDTH and ROW WIDTH values will automatically change.
• Press ENTER to accept the changes
• Press the LINE 3 button to move the focus window to the next section that
requires setting.
• Use the INC/DEC buttons to change the section width.
As the section is changed
the TOTAL WIDTH and ROW WIDTH values will change accordingly
•
Repeat the process for as many section widths that need changing.
• Once all section widths have been entered for that Preset With, then select
another Preset Width Number.
• Press MENU to go back to the previous Spray Setup Screen.
V 1.0 11/05
