E15h SPRAYER- Operations: Sprayer
7.2 TO BEGIN SPRAYING
7.2.1 TO BEGIN SPRAYING (Manual Mode)
• Select a Sub Area Number. Reset Sub Area if necessary.
• Electronically fill the tank.
• Start up Pump.
• Switch any required sections ON.
Corresponding LED’s will flash
• Switch the MASTER switch ON. Corresponding Section LED’s will stay ON
• Drive off.
7.2.2
INCREASE OR DECREASE THE APPLICATION RATE (Manual
Mode)
• Ensure the MASTER switch is ON and any required sections are ON
• Press INC button to increase RATE
• Press DEC button to decrease RATE
The regulator valve will operate and you will see the actual rate change
accordingly
7.2.3 TO BEGIN SPRAYING (AUTO MODE)
• Select a Sub Area Number. Reset Sub Area if necessary.
• Electronically fill the tank.
• Start up Pump.
• Switch any required sections ON.
Corresponding LED’s will flash
• Press AUTO/MANUAL button (LED will turn ON), to spray in AUTO.
• Switch the MASTER switch ON.
Corresponding Section LED’s will stay ON
• Drive off.
7.2.4
CHOOSE A PRESET APPLICATION RATE (Auto Mode)
• Ensure the unit is in AUTO mode as previously described
• Press ‘RATE 1’ button,the preset rate set for ‘RATE 1’ will be displayed in the
‘Application Rate’ window and will control to the rate,
• Press ‘RATE 2’ button,the preset rate set for ‘RATE 2’ will be displayed in the
‘Application Rate’ window and will control to the rate,
7.2.5
INCREASE OR DECREASE THE APPLICATION RATE (Auto Mode)
• Ensure the unit is in AUTO mode as previously described
• Press INC or DEC buttons.
The target rate will change by the set increment
amount and the Application Rate will be displayed in the Application window.
V 1.0 11/05
73
