E15h SPRAYER- Operations: Data Logger
7.3.1
CONNECT THE DATA LOGGER INTERFACE TO THE EAGLE
• Switch the Eagle console OFF
• Connect the circular 9 pin plug from the Data Logger Interface to the matching
plug on the rear of the Eagle
• Switch the Eagle console ON
• Ensure Data Logger Interface is ENABLED. See Section 3.10
• If there is an error connecting to the interface, a Logger Interface Not Found
alarm will be displayed, in the ALARM WINDOW.
7.3.2
CONNECT A MODULE TO THE DATA LOGGER INTERFACE
• Switch the Eagle console OFF
• Connect the Data Logger Module to the designated plug on the Data Logger
Interface
• Switch the Eagle console ON, Data Logger Module is connected
• If there is an error connecting to the module, a DATA MODULE ERR alarm will be
displayed, in the ALARM WINDOW.
7.3.3
REMOVE A MODULE FROM THE DATA LOGGER INTERFACE
• Switch the Eagle console OFF
• Remove the Data Logger Module from the Data Logger Interface
• It is now safe to switch the Eagle console back ON
7.3.4
SPRAY TO A PREPROGRAMMED RATE
• Connect the programmed module to the data logger interface
• Set the SUB AREA (see Section 5.1.8) on the console to the SUB AREA shown on
the job sheet that relates to the required ‘Job Number’.
• Return to the ‘Runtime Screen’
• The ‘Job Number’ and ‘Set Rate’ will be displayed in the bottom left hand corner
of the screen, check against the job sheet to ensure you have loaded the correct
‘Job Number’.
• Set the Eagle console to AUTO, activate the required sections, switch the Master
Switch ON. and begin spraying. The pre-programmed rate will be set as the
TARGET RATE. The Rate can be adjusted by using the INC/DEC buttons. Any
changes in the ‘Rate’ will be logged.
• If a new module is attached or the SUB AREA number is changed, the new
pre-programmed set rate will be loaded in. The pre-programmed ‘Set Rate’ will
always be displayed in the bottom left hand corner of the screen for reference.
V 1.0 11/05
75
