E15h SPRAYER- Sprayer Setup Operation
3.20 ENABLE PUMP SPEED SENSOR
Note: Select ON if a PUMP SPEED SENSOR is fitted to the sprayer loom, to the
plug marked PUMP SPEED. The PUMP SPEED plug is only available on the ‘FULLY
FEATURED HORTICULTURAL LOOM’.
When enabled ON , the PUMP SPEED RPM can be displayed in the FLOW RATE
window.
• Press MENU
• Press ENTER to select SETUP
• Press ENTER to select SPRAYER SETUP
• Press the DEC button to advance to the SPRAYER SETUP 2 screen
• Press the DEC button to advance to the SPRAYER SETUP 3 screen
• Press LINE 1, to highlight PUMP SPEED SENSOR
• Press ENTER to edit the PUMP SPEED SENSOR.
• Press INC/DEC buttons, to enable the PUMP SPEED SENSOR ON or OFF
• Press ENTER to accept changes
3.21
ENABLE AUXILIARY SHAFT SENSOR
Note: Select ON if a AUXILIARY SHAFT SENSOR is fitted to the sprayer loom, to
the plug marked AUXILIARY SHAFT The AUXILIARY SHAFT plug is only available
on the ‘FULLY FEATURED HORTICULTURAL LOOM’.
When enabled ON , the AUXILIARY SHAFT RPM can be displayed in the FLOW
RATE window.
• Press MENU
• Press ENTER to select SETUP
• Press ENTER to select SPRAYER SETUP
• Press the DEC button to advance to the SPRAYER SETUP 2 screen
• Press the DEC button to advance to the SPRAYER SETUP 3 screen
• Press LINE 1, to highlight AUX. SHAFT SENSOR
• Press ENTER to edit the AUX.SHAFT SENSOR.
• Press INC/DEC buttons, to enable the AUX. SHAFT SENSOR ON or OFF
• Press ENTER to accept changes
3.22
ENABLE DUMP OVERRIDE
Note: Select ON to enable the DUMP OVERRIDE feature. This allows a Chemical
Induction Pump to suck premix chemical into the main tank. Don’t enable this
function unless your sprayer has been plumbed up correctly. When enabled ON ,
the DUMP OVERRIDE can be displayed in the VOLUME USED window.
• Press MENU
• Press ENTER to select SETUP
• Press ENTER to select SPRAYER SETUP
• Press the DEC button to advance to the SPRAYER SETUP 2 screen
• Press the DEC button to advance to the SPRAYER SETUP 3 screen
• Press LINE 2, to highlight DUMP OV’RIDE ENABLED
• Press ENTER to edit the DUMP OV’RIDE ENABLED.
• Press INC/DEC buttons, to enable the DUMP OV’RIDE ENABLED ON or OFF
• Press ENTER to accept changes
33
V 1.0 11/05
