E15h SPRAYER- Operations: Sprayer
7.1.13 SELECT BETWEEN VOLUME LEFT and FLUSH FUNCTION
NOTE: To enable the FLUSH FUNCTION see Section 3.16
If the FLUSH FUNCTION is disabled, then only the VOLUME LEFT will be displayed
in the window.
With VOLUME LEFT displayed:
• Press LINE 3 to highlight the VOLUME LEFT window. Only stays highlighted for
5 seconds.
• Press AUX button with the focus on the VOLUME LEFT window, FLUSH will be
displayed
• Press AUX button again within 5 seconds,VOLUME LEFT will be displayed.
What ever was displayed last will stay on the FLOW RATE window.
7.1.14 SELECT BETWEEN VOLUME USED, AUXILIARY FUNCTION,
DUMP OVERRIDE, and DATA LOGGER
NOTE: To switch between AUXILIARY FUNCTION, DUMP OVERRIDE and DATA
LOGGER they have to be enabled. To enable the AUXILIARY FUNCTION,(see
section 3.20 to set), to enable DUMP OVERRIDE see (Section 3.24). to enable the
DATA LOGGER see (Section 3.14) Only the functions enabled will appear in the
VOLUME USED window.
If ALL functions are disabled, then only the VOLUME USED will be displayed in
the window.
With VOLUME USED displayed:
• Press LINE 4 to highlight the VOLUME USED window. Only stays highlighted for
5 seconds.
• Press AUX button with the focus on the VOLUME USED window, AUXILIARY
will be displayed.
• Press AUX button again within 5 seconds, DUMP OVERRIDE will be displayed.
• Press AUX button again within 5 seconds, DATA LOGGER screen will be
displayed.
• Press AUX button again within 5 seconds, VOLUME USED will be displayed.
What ever was displayed last will stay on the VOLUME USED window.
7.1.15 SELECT A ROW WIDTH
Note: There are 4 Preset ROW WIDTHS to choose from. The actual ROW WIDTH is
displayed on the right hand side of the window. The Preset Width number is
displayed in brackets. To set the 4 preset ROW WIDTHS, see Section 3.4.
• Switch the Master Switch OFF
• Press the ‘LINE 2’ button TWICE, to highlight the COVERAGE RATE window.
• Press the AUX. button, until ROW WIDTH is displayed.
• Press the ENTER button while ROW WIDTH is highlighted.
An asterisk will
appear.
• Press INC/DEC buttons to select a Preset Row Width. There are 4 Row Widths to
select from. The corresponding Row Width, a number will appear in the
brackets (1,2,3 and 4) representing the ‘Preset Width’ number.
• Press ENTER to accept the new ROW WIDTH.
