E15h SPRAYER- Sprayer Setup Operation
3.9.1 AUTOMATIC FLOW CALIBRATION
• Fully prime the flow sensor and hose
• Disconnect one of the section lines from the spray manifold
• Place a bucket under the output of the section valve
• Ensure the relevant boom section switch is switched ON, on the console.
• Press ENTER to begin flow factor calculation
• The valve will open and fluid will begin to pump through the manifold.
The
pulse count will begin accumulating as you meter out liquid
• Once a sufficient volume has accumulated( 20 litres is a good amount), press
ENTER, this will automatically turn OFF the section valve. The
Focus will
automatically jump to ACTUAL FLOW line of the screen
• Use INC/DEC buttons to change the volume, to reflect the actual
volume collected in the bucket
• Press ENTER to accept the value.
Flow cal factor will be automatically
calculated and displayed.
3.9.2 MANUAL FLOW CALIBRATION
Note: If the Flow Meter has a ‘Flow Cal’ value stamped on the flow meter then
that value can be entered in here. The value must be in “pulses per volume”. The
units that are stamped on the‘Flow Cal’, must be the same units, the E15 console
is using; otherwise a conversion will have to be performed.
• Press LINE 3 until the focus is on FLOW CAL
• Press ENTER to edit the value
• Press INC/DEC buttons to change the FLOW CAL factor
• Press ENTER to accept the value
Note: Press MENU to get back to the previous Sprayer Setup Screen once the
calibration is finished.
