E15h SPRAYER- Operations: Sprayer
7.1.7 TO CLEAR SUB AREA
• Ensure the SUB AREA is displayed in the LINE 2 window.
If the SUB AREA isn’t
in the focus window, Press LINE 2 button and then keeping pressing the AUX
button until the SUB AREA is displayed.
• Press and hold the LINE 2 button for 5 seconds with the SUB AREA display on
the screen.
• The SUB AREA will be reset to zero, for that SUB AREA NUMBER.
7.1.8
TO CHANGE THE SUB AREA NUMBER
• Press LINE 2,
and while the SUB AREA window is highlighted.
• Press AUX button once,
SUB AREA NUMBER will be displayed
• Press ENTER, ensuring the focus is on SUB AREA NUMBER.
An asterisk (*) will
appear.
• Press INC/DEC buttons, to change the SUB AREA NUMBER.
The VOLUME USED will change accordingly.
• Press ENTER, to accept the new SUB AREA NUMBER
7.1.9
RESET TOTAL AREA
• To reset the TOTAL AREA, see Section 6.1.3
7.1.10 SELECT BETWEEN MANUAL AND AUTO SPRAYING
• Press AUTO/MANUAL button to switch between AUTO and MANUAL spraying.
• If the sprayer is in AUTO mode, the LED next to the AUTO/MANUAL button will
be illuminated and the preset button (RATE 1 or RATE 2) that is selected will
have its LED illuminated.
• If the unit is in MANUAL mode the AUTO/MANUAL button LED will not be
illuminated and the selected preset rate button (RATE 1 or RATE 2) LED will
be flashing.
68
V 1.0 11/05
