E15h SPRAYER- Sprayer Setup Operation
3.32 PRESSURE SENSOR 1 CALIBRATION
Note: A “Glass Pressure Gauge” should be connected as close to the electronic
pressure sensor as possible. The “Glass Gauge” will give the actual pressure, so
the electronic pressure transducer can be calibrated.
• Press MENU
• Press ENTER to select SETUP
• Press ENTER to select SPRAYER SETUP
• Press the DEC button to advance to the SPRAYER SETUP 2 screen
• Press the DEC button to advance to the SPRAYER SETUP 3 screen
• Press the DEC button to advance to the SPRAYER SETUP 4 screen
• Press LINE 2 to highlight PRESSURE CAL
• Press ENTER,
screen will change to Pressure Calibration Screen. ‘TURN PUMP
OFF’. is highlighted
• Turn pump OFF
. Make sure the spray pump is turned OFF
• Press ENTER.
The focus window will move to the next window ‘IS PUMP OFF?’
then Press ENTER. at this point the Eagle console is taking a zero point for the
electronic pressure sensor while the spray pump is switched OFF.
• Switch the pump ON; switch the sections ON; switch the MASTER ON; and take
the pump up to ‘operating pressure’; once at operating pressure.
• Press ENTER the focus window will move to ‘IS PUMP AT OPERATING
PRESSURE’, reminding the operator to have the spray pump at operating
pressure.
• Press ENTER again to move the focus window to ACTUAL PRESSURE.
• Press ENTER to edit the ACTUAL PRESSURE.
An asterisk (*) will appear.
• Press the INC/DEC buttons, till the actual pressure as displayed by the
“Glass Pressure Gauge” is reflected in ACTUAL PRESSURE” window.
• Press ENTER to accept changes
V 1.0 11/05
39
