E15h SPRAYER- Specifications
11.3.2 Polmac
• 3 Wire Flow Sensor
• Flow Rate: 20 - 200 l/min
• Calibration: approx: 630 pulse/l
• Accuracy: +/- 1% when flow is 10-100 l/min
+/- 3 % when flow is 100 - 200 l/min
• Bore: 25 mm
11.3.3 Polmac
• 3 Wire Flow Sensor
• Flow Rate: 2-20 l/min
• Calibration: approx: 630 pulse/l
• Accuracy: +/- 1% when flow is 2-20 l/min
• Bore: 25 mm
11.4
PRESSURE TRANSDUCER
• VDO type 360 710 Variable resistance sender fitted with gauge saver.
• 0kPa Pressure 8-11 Ohms
• 500 kPa Pressure approx. 180 Ohms
99
V 1.0 11/05
