One to one Mapping
If one to one mapping is required the spreadsheet is still required to set-up the master node
address, Start address and number of registers. The output can then be entered in channel
order to configure the one to one mapping.
Alternatively if the user sets mapped port to None in the mapping tab the unit will default to
one to one on all ports
NOTE:
Any gaps in the annunciator cells must be repeated in the spreadsheet, so only valid
cells are shown. For example with medium windows every other cell is used.
i.e. Cell 0, Cell 2, cell 4 etc.
