1.4 Annunciator Model Code Definition
Code Description
Model No
B
Range RTK 725B
Window Size
S
Small – 30 mm w x 30mm h
M
Medium – 60mm w x 30mm h
L
Large – 60mm w x 60mm h
I
Intermixed – combinations of the above as required
Cells Wide
1-G
1 =1 cell wide to 9 = 9 cells wide
A = 10 cells wide to G = 16 cells wide
Cells High
1-G
1 =1 cell high to 9 = 9 cells high
A = 10 cells high to G = 16 cells high
Pushbutton
Module
X
Not fitted
P
Integral
R
Remote TAR
Number Of Active
Alarms
0
Hundreds
3
Tenths
2
Units - Example shown = 32 ways
Repeat Relay
Facility
X
Not fitted
R
Single repeat relay per channel
D
Dual repeat relay per channel
C
Repeat relays powered by signal voltage
Integral Power
Supply
X
Not fitted
U
Universal Input Power Supply – 85 to 264VAC OR 88 to 300VDC
S
Universal Input Power Supply with SMR (Supply Monitor Relays)
D
Redundant Universal Input Power Supplies - 85 to 264VAC OR 88 to 300VDC
M
Dual Redundant with SMR(Supply Monitor Relays)
Signal Input Type
A
24v standard FCV
B
48v standard FCV
C
125v standard FCV
D
n/a
E
24v diff inputs FCV
F
48v diff inputs FCV
G
125v diff inputs FCV
H
n/a
I
Intermixed cards
Code Description
