65
Window Style Window Size mm Alarms PER cell
Large 60 W x 60 H 1
Medium 60 W x 30 H 2
Small 30 W x 30 H 4
8.5 19” Rack Mounting
RTK 725B Alarm Annunciators are suitable for mounting within 19” racks using suitable filler
plates which can be supplied as optional items.
Units from 1 to 7 cells wide are possible within the 19” rack dimensional limits
The number of cells high is dependent on the available space available within the 19” rack.
8.6 Wall Mounting
We offer a full integration service where Panel mounted Annunciators are supplied within an
industry standard Wall mounting Enclosure, with all customer connections typically wired to
Weidmuller terminals for ease of connection to the field device.
8.7 Floor Mounting
We offer a full integration service where Panel mounted Annunciators are supplied within an
industry standard Floor Standing Enclosures, with all customer connections typically wired to
Weidmuller terminals for ease of connection to the field device.
