13.4.24 IEC61850 Server
The IEC61850 is available on Port 3 and can provide the following data onto the network:
• Input Status
• Alarm Status
• Pushbutton status
• Internal Status
• Disable Status
This data will be time stamped to 1ms and will be available via polling or buffered reporting
(RCB’s).
NOTE
Each event type must be enabled via the configuration software to make it available on
the IEC61850 network.
The RTK 725B can also be configured to allow for the following to be controlled on the
annunciator via IEC61850 using Single point control (SPC):
• Inputs
• Pushbuttons
NOTE:
Inputs and pushbuttons must be configured as Remote to be controlled via IEC61850
As default the device is loaded a Generic SCL file, which is taken from the ICD file for the
device. The default IED name will be RTK 725B.
As default the following configuration will be provided:
BRCB’s
• Rep1 - reporting data and quality change of Input dataset
• Rep2 - reporting data and quality change of Internal dataset
• Rep3 - reporting data and quality change of pushbutton dataset
• Rep4 - reporting data and quality change of card_status dataset
• Rep5 - reporting data and quality change of alarm dataset
NOTE:
Event type must be enabled in the configuration software otherwise no data change
will be reported
Datasets
• Internal - All internal status inc quality and timestamp
• Card_Status - All alarm card status inc quality and timestamp
• Pushbuttons - All pushbutton inc quality and timestamp
• Input_Status - All input channels status only
• Inputs - All input status inc quality and timestamp
• Alarms - All alarm status inc quality and timestamp
• Disable - All disable status inc quality and timestamp
Note:
If device has more than 100 inputs then these will be spilt across 2 data sets.
