170
Technical Publication Document NO: SYSTEM-007-ENG (Ver.1.1)
HF-525Plus Installation, Operation and Service Manual
● Pic 4
(1) Select Exposure Direction (Body direction).
(2) 4 directions are selectable - AP, PA, LAT, OBL.
(3) F4 key can change the direction, the icon displays on LCD screen.
(4) Followings are directions to select.
With Foot selected, press F3 to select at ‘Tibia’ then its
body part appears on LCD screen.
With Foot selected, press F3 to select at ‘Knee’ then its
body part appears on LCD screen.
