Technical Publication Document NO: SYSTEM-007-ENG (Ver.1.1)
HF-525Plus Installation, Operation and Service Manual
C-Spine
AP
70
320
60
19.2
LAT
71
320
40
12.8
OBL
70
320
35
11.2
L-Spine
AP
76
320
120
38.4
LAT
82
320
150
48
OBL
78
320
130
41.6
T-Spine
AP
72
320
70
22.4
LAT
80
320
90
28.8
OBL
76
320
60
19.2
Abdomen
AP
74
320
60
19.2
LAT
80
320
95
30.4
OBL
78
320
60
19.2
Pelvis
AP
77
320
85
27.2
LAT
80
320
100
32
OBL
76
320
110
35.2
Hip Bone
AP
76
320
40
12.8
LAT
84
320
40
12.8
OBL
80
320
50
16
kV
mA
mSec
mAs
Hand
AP
42
320
3
0.96
LAT
43
320
4
1.28
OBL
44
320
3
0.96
Elbow
AP
49
320
8
2.56
LAT
51
320
8
2.56
OBL
48
320
8
2.56
Forearm
AP
49
320
7
2.24
LAT
51
320
7
2.24
OBL
48
320
7
2.24
Foot
AP
42
320
3
0.96
LAT
43
320
4
1.28
OBL
44
320
3
0.96
Ankle
AP
55
320
11
3.52
LAT
57
320
11
3.52
OBL
55
320
11
3.52
Tibia
AP
57
320
17
5.44
LAT
59
320
17
5.44
OBL
56
320
17
5.44
Femur
AP
49
320
8
2.56
