Ecoray HF-525Plus - Page 231

231
Technical Publication Document NO: SYSTEM-007-ENG (Ver.1.1)
HF-525Plus Installation, Operation and Service Manual
LAT
53
320
8
2.56
OBL
48
320
8
2.56
Knee
AP
60
320
17
5.44
LAT
61
320
17
5.44
OBL
57
320
17
5.44
Aux1
AP
78
320
55
17.6
LAT
83
320
70
22.4
OBL
78
320
60
19.2
Aux2
AP
78
320
55
17.6
LAT
83
320
70
22.4
OBL
78
320
60
19.2
Aux3
AP
78
320
55
17.6
LAT
83
320
70
22.4
OBL
78
320
60
19.2
Aux4
AP
78
320
55
17.6
LAT
83
320
70
22.4
OBL
78
320
60
19.2
Icon
Function
Extra set for APR (Auxiliary)
kV
mA
mSec
mAs
Skull
AP
66
320
20
6.4
LAT
74
320
55
17.6
OBL
75
320
40
12.8
Mandible
AP
64
320
35
11.2
LAT
71
320
50
16
OBL
70
320
40
12.8
Nasal
AP
68
320
35
11.2
LAT
71
320
40
12.8
OBL
68
320
40
12.8
Chest
AP
70
320
60
19.2
LAT
67
320
50
16
OBL
66
320
40
12.8
Shoulder
AP
64
320
40
12.8
LAT
61
320
35
11.2
